UOMeach
UPC026715201044
Sones1.5
Width13.75"
FinishWhite
Height7.63"
Length13"
Weight10 lbs.
Cfm Hvi130
LightedYes
ListingUL
Type IcYes
Voltage120v
Wattage37.1
IncludesUnique spacer for mounting to ''I'' joists, 6'' round damper/duct connector and 6'' round to 4'' round duct reducer
ShippingL:16"x W:13.2"x H:15.5" 12 lbs.
Warranty3 Years
Duct Size6''
Ul ListedYes
CollectionQT™ Series
Duct ShapeRound
NightlightYes
ENERGY STARYes
Ceiling OnlyYes
Frequency Hz60
Grille ShapeRectangle
Product LineBroan
Product TypeFan Only Exhaust Fan
Amperage Amps1
Hvi VertifiedYes
Lighting TypeLED
Duct DirectionHorizontal/Vertical
Air Flow MethodCentrifugal Blower
Grille MaterialPlastic
Grille Width In13.75
Lights IncludedYes
Motor Speed Rpm750
Grille Height In2.3
Housing MaterialGalvanized
Housing Width In11.38
Country of OriginChina
Hardware IncludedYes
Housing Height In7.63
Installation TypeCeiling
Online Product ID10770852
Lumens Light Source850
Bulb Recommended TypeGU24
Certification File NoE17814
Energy Star CertifiedYes
Housing Dimensions In10-1/2'' X 11-3/8'' X 7-5/8''
Grille Length Depth In13
Minimum Order Quantity1
Ceiling Cutout Width In11
Housing Length Depth In10.5
Ceiling Cutout Length In11.9
Lighting Modules Number Of2
Radiation Damper AvailableYes
Product Switch Control TypeWall Control
Recommended Room Size Sq Ft125
Contain Electronic EquipmentYes
Minimum Construction Space Required2'' x 8''
