Broan Nutone Heater Ventilation Fan with LED - 80 CFM - 1.5 Sones in Bright White
Item #: BHFLED80H
UPC: 026715265510
Free Shipping on LTL freight orders over $99
Overview
- Product Type: Light And Heat Combo Exhaust Fan
- Finish: Bright White
- Length: 14.25"
- Width: 8.25"
- Height: 5.87"
- Weight: 4.75 lbs.
Features
- Mounting bars for ease of installation
- Built in damper to reduce the amount of air leakage
- Corrosion resistant galvanized steel housing stands up to moisture
- Housing and finish packs sold separately
- Built in damper to reduce the amount of air leakage
- To install this product, a dedicated 20 amp circuit is required.
Specifications
Product Specifications
| Sones | 1.5 |
|---|---|
| Finish | Bright White |
| Cfm Hvi | 80 |
| Includes | Hardware |
| Shipping | L:17.52"x W:15.36"x H:12.96" 5.25 lbs. |
| Warranty | 1 Year |
| Duct Size | 4'' |
| Ul Listed | Yes |
| Cul Listed | Yes |
| Duct Shape | Round or Rectangular |
| Heater Type | Surface Mount Ceiling |
| Ceiling Only | Yes |
| Culus Listed | Yes |
| Product Line | Broan |
| Product Type | Light And Heat Combo Exhaust Fan |
| Project Pack | Yes |
| Hvi Vertified | Yes |
| Duct Direction | Horizontal/Vertical |
| Air Flow Method | Centrifugal Blower |
| Lights Included | Yes |
| Sones Max Rating | 1.5 |
| Installation Type | Ceiling |
| Online Product ID | 10770815 |
| Bulb Recommended Type | Integrated LED Module |
| Minimum Order Quantity | 4 |
| For Commercial Applications | Yes |
| Product Switch Control Type | Wall Control |
| Recommended Room Size Sq Ft | 75 |
| Room Side Installation Possibile | Yes |
Dimensions
| Width | 8.25" |
|---|---|
| Height | 5.87" |
| Length | 14.25" |
| Weight | 4.75 lbs. |
| Housing Width In | 8.25 |
| Housing Height In | 5.87 |
| Housing Dimensions In | 14.25x8.25x5.87 |
| Housing Length Depth In | 14.25 |
Materials
| Grille Material | Plastic |
|---|---|
| Housing Material | Galvanized |
