Kohler Archer 60'' x 30'' alcove whirlpool bath, right drain - Biscuit

Name: Kohler Archer 60'' x 30'' alcove whirlpool bath, right drain - Biscuit
Brand: Kohler
SKU: 1947-RA-96
Price: 3047.71 USD
Availability: OutOfStock

Item #: 1947-RA-96UPC: 885612200396Finish: Biscuit

$3,585.55 MSRP

Offered in 2 finishes

Selected: Biscuit

ADAPROP65TITLE24

Description

Taking its design cues from traditional Craftsman furniture, the KOHLER® Archer line of baths reveals beveled edges and curved bases for a clean, sophisticated style. This 60" x 30" rectangular alcove bath offers a low step-over height while allowing deep, comfortable soaking. Whirlpool jets relax away the day's tension as armrests and a lumbar arch gently support the natural curves of your body.

Features

Single-speed whirlpool offers performance and value with 8 fully adjustable jets
Hydromassage flow and direction can be controlled at each jet
Comfort Depth® design offers a convenient 19" step-over height while retaining the same depth as a standard 21" bath
Integral lumbar support
Slotted overflow allows for deep soaking
Integral apron
Integral flange helps prevent water from seeping behind wall and simplifies alcove installation
Coordinates with other products in the Archer collection

Materials

Acrylic

Specifications

ADAYes

UOMeach

UPC885612200396

GTIN00885612200396

ShapeRectangle

Width30"

FinishBiscuit

Height20.25"

Length60"

Weight173.000

MaterialAcrylic

ShippingL:62.66"x W:35.31"x H:22.19" 173 lbs.

OversizedYes

backorderfalse

CollectionArcher

Product LineArcher

Product TypeThree Wall Alcove Whirlpool Bathtub

review_count0

stock_statusin_stock

variant_skus1947-RA-0,1947-RA-7,1947-RA-95,1947-RA-96

Product StyleTraditional

special_orderfalse

Asme StandardsASME A112.19.7/CSA B45.10

Product WarrantyKOHLER® Plastic Baths and Shower Bases Lifetime Limited Warranty|KOHLER® Hydrotherapy Components Five-Year Limited Warranty

Country of OriginUS

Introduction Date4/12/2013

Online Product ID549782

freight_policy_type4

review_rating_range5

Overall Width Inches30"

release_for_shipment2013-04-12T00:00:00Z

Csa Product StandardsCSA B45.5/IAPMO Z124

Overall Height Inches20-1/4"

Overall Length Inches60"

Documents

3D DWG Symbol 3D DXF Symbol 3D Model (3DS)3D Model (OBJ)Revit Family (RFA)SketchUp Model (SKP)DWG Front View DWG Plan View DWG Side View DXF Front View DXF Plan View DXF Side View Installation Guide Parts Diagram Parts Diagram Parts Diagram Homeowners Guide Technical Specifications

gerhardsstore.comItem #: 1947-RA-96

Kohler Archer 60'' x 30'' alcove whirlpool bath, right drain - Biscuit by Kohler

Hover to zoom

Kohler Archer 60″ x 30″ alcove whirlpool bath, right drain - Biscuit

Item #: 1947-RA-96

UPC: 885612200396

Finish: Biscuit

Offered in 2 finishes

Selected: Biscuit

Archer® 60'' x 30'' alcove whirlpool bath, right drain

Features

Single-speed whirlpool offers performance and value with 8 fully adjustable jets
Hydromassage flow and direction can be controlled at each jet
Comfort Depth® design offers a convenient 19" step-over height while retaining the same depth as a standard 21" bath
Integral lumbar support
Slotted overflow allows for deep soaking
Integral apron
Integral flange helps prevent water from seeping behind wall and simplifies alcove installation
Coordinates with other products in the Archer collection

Materials

Acrylic

Installation

Alcove

Certifications & Compliance

ADA CompliantPROP 65Title 24

Warranty	KOHLER® Plastic Baths and Shower Bases Lifetime Limited Warranty\|KOHLER® Hydrotherapy Components Five-Year Limited Warranty
Country of Origin	US

Replacement Parts

	Part Number	Description	Price
—	90105	Air Switch Assembly	—
	K-91967	Assembly, Check Valve	$25.92	View
—	96895	Cover, Suction	—
	K-67429	Flange	$7.95	View
	K-96708	Flange, Suction	$8.85	View
—	91575	Flange, Switch	—
—	65156	Flange, Switch	—
	K-1146912	Flex Tube, 3/8"	$2.28	View
—	67668	Gasket, Tapered	—
	K-65886	Gasket, Tapered	$5.05	View
	K-65885	Gasket, Tapered	$6.17	View
	K-1008241	Gasket, Tapered	$3.39	View
	K-1011001	Jet Flange Tool	$285.57	View
	K-1008239	Jet Flange, Retail	$4.95	View
	K-1013249	Jet Nozzle	$4.71	View
	K-1013250	Jet Nozzle Nut	$4.54	View
	K-1287280	Kit, Manifold	$193.80	View
	K-93838	Kohler Genuine Parts 1 PVC Tube, Service KIT	$53.58	View
	K-93839	Kohler Genuine Parts 1.25 PVC TUBE Service KIT	$264.57	View
	K-93836	Kohler Genuine Parts 1/2 PVC TUBE Service KIT	$46.16	View
	K-65061-AF	Kohler Genuine Parts Cover, Suction - French Gold	from $106.95	Brushed Black Pvd — $158.15 Brushed Chrome — $163.50 French Gold — $111.95 Polished Chrome — $106.95 Polished Nickel — $195.90 Vibrant Brushed Bronze — $180.30 Vibrant Brushed Nickel — $162.27 Vibrant Finish — $195.90
	K-67889	Kohler Genuine Parts Housing Assy, PVC JET	$23.40	View
	K-93685	Kohler Genuine Parts Housing Assy, Suction	$30.40	View
	K-1101695-NY	Kohler Genuine Parts JET Handle Assembly - Dune	$12.87	View
	K-1008238	Kohler Genuine Parts JET Housing, Retail	$20.09	View
	K-1015255-96	Kohler Genuine Parts JET TRIM KIT - Biscuit	from $73.89	Almond — $76.24 Biscuit — $86.85 Black Black — $73.89 Ice Grey — $73.89 White — $85.55
	K-1147742-96	Kohler Genuine Parts KIT, AIR Switch - Biscuit	from $24.75	Almond — $34.02 Biscuit — $24.75 Black Black — $41.40 Cashmere — $41.40 Dune — $42.90 White — $28.80
	K-1330132	Kohler Genuine Parts KIT, Manifold, 2 BARB	$452.70	View
	K-65157	Kohler Genuine Parts NUT, 1.5625-16UNR-2B	$7.45	View
	K-1045715-P	Kohler Genuine Parts Packet, Dc-111 LUBE	$3.40	View
	K-65226-96	Kohler Genuine Parts Plug, Suction Cover - Biscuit	from $4.10	Biscuit — $4.38 Black Black — $4.38 Desert Bloom — $4.38 Ice Grey — $4.38 Tender Grey — $4.38 Thunder Grey — $4.10 White — $4.60
	K-30739	Kohler Genuine Parts Removal Tool, DIR. BALL	$8.20	View
	K-65054-BA	Kohler Genuine Parts Screw, 10-24 X 3.25 - Vib Bright Bronze	from $4.50	Brushed Black Pvd — $8.25 Polished Stainless — $7.63 Vib Bright Bronze — $5.60 Vib Bright Nickel — $7.29 Vibrant Bright French Gold — $4.50 Vibrant Finish — $8.15
	K-94853	Kohler Genuine Parts Service KIT, 1 1/2 FLEX	$40.30	View
	K-88532-96	Kohler Genuine Parts TRIM RING KIT - Biscuit	from $34.42	Almond — $50.13 Biscuit — $34.62 Black Black — $50.13 Dune — $50.13 Ice Grey — $50.13 Sandbar — $50.13 White — $34.42
	K-88530-96	Kohler Genuine Parts TRIM RING KIT - Biscuit	from $37.10	Almond — $55.89 Biscuit — $41.10 Black Black — $89.55 Cashmere — $62.10 Ice Grey — $55.89 Sandbar — $55.89 White — $37.10
	K-88531-BKB	Kohler Genuine Parts TRIM RING KIT - Brushed Black Pvd	from $179.28	Brushed Black Pvd — $254.10 Polished Chrome — $179.28 Vibrant Brushed Nickel — $250.20 Vibrant Finish — $244.00
	K-88529-AF	Kohler Genuine Parts TRIM RING KIT - French Gold	from $137.85	Brushed Black Pvd — $260.40 French Gold — $250.30 Polished Chrome — $137.85 Polished Nickel — $250.30 Vibrant Brushed Bronze — $256.60 Vibrant Brushed Nickel — $256.60 Vibrant Finish — $250.30
	K-1011031-96	Kohler Genuine Parts TRIM RING KIT, Large Orifice - Biscuit	from $30.60	Biscuit — $44.64 White — $30.60
	K-1011032-96	Kohler Genuine Parts TRIM RING KIT, Large Orifice - Biscuit	from $34.42	Biscuit — $37.93 White — $34.42
	K-1003065	Kohler Genuine Parts Tool, Suction Flange	$462.04	View
	K-1020609	Kohler Genuine Parts Tube, 1/16 ID, 6 FT. LONG	$3.87	View
	K-1086350	Kohler Genuine Parts Wrench, Flange Removal	$200.43	View
	K-65451	O-Ring	$2.30	View
	K-67665	Pipe Plug-1"	$4.54	View
	K-73518	Plug, 1.5" Pvc	$10.10	View
	1145781	Sterling Plumbing 25R Fitting Union TEE, 3/8	$2.37	View
	K-1265445	Tool, Jet Removal	$11.20	View
	K-1226809	V-Jet Housing	$10.55	View
—	73521	—	—
—	60050	—	—
—	1010571	—	—
—	93837	—	—
—	67594	—	—
—	93766	—	—
—	73513	—	—
—	73584	—	—
